Outdoor Led Sign Panels Billboard P3.91 with 500x500mm cabinet and3840hz refresh rate

Brightness : 6500cd/㎡

Input Voltage : AC220V/50Hz

Module Size : 250x250mm

Operating Temperature : -20℃-50℃

Power Consumption : 800W/㎡

Cabinet : Iron or Aluminum For Options

Gray Scale : 16bit

Brand Name : SCX

Model Number : outdoor p3.9

Certification : CE,CB,IEICC,FC

Place of Origin : shenzhen,China

MOQ : 11 sqm

Price : negotiation

Payment Terms : T/T, Western Union

Supply Ability : 3700 sqm per sqm

Delivery Time : 5-7 working days

Packaging Details : wooden case，flight case

Refresh Rate : 3840Hz

Installation Type : Wall-mounted / Hanging / Fixed installation

Lifespan : 100000 Hours

Power Supply : MEANWELL

Switch Power Loading : 5V/40A

Control System : Asynchronous or Synchronous control

Contact Now

Rental Billboard P3.91 LED Screen Panel Cheap Video Wall Indoor Outdoor Advertising Screen Stage Led Display

Case

Outdoor Led Sign Panels Billboard P3.91 with 500x500mm cabinet and3840hz refresh rate

Indoor P3.91.

Total area: 30sqm 500*500mm
  Brightness: ≥1300cd/㎡
  Refresh Rate: ≥1920HZ
  Location : Senegal, Africa

Indoor P3.91.

Total area: 30sqm 500*500mm
  Brightness: ≥1300cd/㎡
  Refresh Rate: ≥1920HZ
  Location : Senegal, Africa

Indoor P3.91 with protective corner.

Cabinet Quantity: 40pcs 500*500mm
  Brightness: ≥1300cd/㎡
  Refresh Rate: ≥3840HZ
  Location : Philippines, Asia

Outdoor P3.91.

Cabinet Quantity: 45pcs 500*500mm
  Brightness: ≥4000cd/㎡
  Refresh Rate: ≥1920HZ
  Location : Philippines, Asia

Indoor P3.91.

Cabinet Quantity: 40pcs 500*500mm
  Brightness: ≥1300cd/㎡
  Refresh Rate: ≥3840HZ
  Location : Poland, Europe

Outdoor P3.91.

Cabinet Quantity: 80pcs 500*500mm
  Brightness: ≥4000cd/㎡
  Refresh Rate: ≥3840HZ
  Location : USA, North America

Indoor P3.91.

Cabinet Quantity: 32pcs 500*500mm
  Brightness: ≥1300cd/㎡
  Refresh Rate: ≥3840HZ
  Location : Iraq, Asia

Outdoor P3.91.

Cabinet Quantity: 45pcs 500*500mm
  Brightness: ≥4000cd/㎡
  Refresh Rate: ≥1920HZ
  Location : Philippines, Asia

Product Specifications

ITEM	HD OUTDOOR RENTAL INSTALLATION LED SCREENS
Product model	SJ-P2.604	SJ-P2.976	SJ-P3.91	SJ-P4.81	SJ-P5.95	SJ-P6.25
Pixel pitch	2.604mm	2.976mm	3.91mm	4.81mm	5.95mm	6.25mm
Physical density	147456dots/m²	112896dots/m²	65536dots/m²	43264dots/m²	28224dots/m²	25600dots/m²
LED Package	SMD 1415 (3in1)		Nation Star SMD 1921 (3in1)	SMD2727 (3in1)
Module size	250mm*250mm
Modules resolution	96*96	84*84	64*64	52*52	42*42	40*40
Modules weight	0.75±0.01kg
Driving method	1/30S	1/21S	1/16S	1/13S	1/7S	1/10S
Interface definition	HUB-16P
Cabinet size	500mm500mm85mm / 500mm1000mm85mm
Cabinets weight	8.6kg/16kg
Cabinets resolution	192192 192384	168168 168336	128128 128256	104104 104208	8484 84168	8080 80160
Equilibrium brightness	4500-6500cd/m²			5000-7500cd/m²
Power consumption	Max: ≤880W/m², Average: ≤400W/m²			Max: ≤700W/m², Average: ≤350W/m²
Refresh rate	≥3840Hz (ICN2055 Driving IC)
Viewing angle Level	H: ≥160°Optional, V: ≥120°Optional
Viewing distance	2.5-30m	3-40m	4-60m	5-70m	6-80m	6.5-90m
Temperature	Working : -25℃~60℃, Storage: -35℃~80℃
Humidity	10%~95%
Working voltage	Input: AC 100V~240V, 50Hz/60Hz, Output: DC 5V
Maintenance method	Front/Back service
Protection grade	Front: IP65, Back: IP65
Lifetime	100000 Hours
